Manifa field development - Upstream pipeline
Oil & Gas
Location: Manifa Field – Eastern province
Client: Saudi Aramco
Contract Value: 313,000,000 SR
Main Contractor: Consortium of APM/Petrojet
Engineering and Procurement: Petrojet
Construction & Commissioning: Petrojet/APM
Schedule: Oct – 2008 to Jun - 2013
Scope covers EPC for the following pipelines and associated facilities
‒ 24” crude pipeline (60 Km)
‒ 10”, 16” and 20” water injection pipelines (total length 90 Km)
‒ 16 launcher, receivers and valve stations
AH Crude Oil, sales Gas and Ethane Pipelines
Oil &Gas
Location: Jubail – Eastern province
Client: Saudi Aramco
Contract Value: 69,000,000 SR
Main Contractor: Consortium of APM/Petrojet
Engineering and Procurement: Petrojet
Construction & Commissioning: Petrojet/APM
Schedule: Jul – 2011 to Jun - 2013
Scope covers EPC for the following facilities
‒ Crude processing, gas filtering and pressure reduction station (civil, structural steel,
piping mechanical and E & I)
‒ 3 * 24” pipelines with launchers and receivers
‒ Main control building (1000 M2)
DUBA Permanent Berth
Oil & Gas - Offshore
• Location: DUBA, Red Sea – Western province
• Client: Saudi Aramco
• Contract value : 85,000,000 SR
• Main Contractor: APM
• Structures Fabrication: Petrojet
• Offshore installation: PMS
• Schedule: Jun – 2004 to Dec – 2005
• Scope covers Fabrication, transportation, off & onshore installation of the Berth components
‒ Main platform (800 m2 – 2700 tons)
‒ 4 Mooring Dolphins & 2 Breasting Dolphins
‒ Interconnecting Bridge between the Platform and Causeway
‒ 4 Catwalks and 14 piles
Nuayiem ASL Crude Increment Pipelines
Oil & Gas
• Location: Southern Area
• Client: Saudi Aramco
• Contract Value : 114,000,000 SR
• Main Contractor: APM
• Engineering & Procurement: Petrojet
• Construction & Commissioning: Petrojet/APM
• Schedule: Nov – 2006 to Dec - 2008
• Scope covers EPC for the following pipelines and associated facilities
‒ 16” Gas pipeline (120 Km)
‒ 3 * 20” Crude pipelines (40 Km)
‒ 2 * 8” & 10” Water pipelines (20 Km)
Fabrication & Installation of Subsea pipelines & Cables
Oil & Gas - Offshore
• Location: Safanya Field – Eastern province
• Client: Saudi Aramco
• Contract Value: 425,000,000 SR
• Main Contractor: APM
• Fabrication: APM
• Offshore transportation & installation: PMS
• Schedule: Aug – 2006 to Dec - 2011
• Scope covers Fabrication, transportation and installation for the following facilities.
‒ 17 subsea pipelines (total length 80 Km)
‒ Interconnecting piping spools (153 spools)
‒ 10 subsea cables and termination to platforms
‒ Associated structural steel
